55 紅外接收頭系列
紅外產品系列
產品特點 / Feature
01
應用：電視機、空調、掃地機、等家電產品
02
玩具、電腦周邊、相關遙控產品等
Ta=25℃
Model No. | Supply Voltage | Supply Current | Receiving Distance | B.D.F Center Frequency | Peak Wavelength | Half Angle |
H55MDP12A0CN01 | 2.7-5.5V | 0.22mA | 18m | 38KHz | 940nm | 45° |
