Φ5系列
直插型發光二極管
產品特點 / Feature
01
高可靠性和長壽命，工藝成熟，市場通用性高
02
可用于3C指示和信號類產
極限參數 / Limit parameters
| 正向電流 | 正向脈沖電流 | 反向電壓 | 工作溫度 | 存儲溫度 |
| IF | IFP | VR | Topr | Tstg |
| 20mA | 100mA | 5V | -40℃~85℃ | -40℃~85℃ |
Ta=25℃
Model No. | Color | Voltage | Luminous | Wavelength | Angle |
H05AXV2XXXXXXX | R n | 1.8-2.6V | 1-40000mcd | 615-660nm | 15°-180° |
H05AXA2XXXXXXX | A n | 1.8-2.6V | 1-40000mcd | 600-615nm | 15°-180° |
H05AXY2XXXXXXX | Y n | 1.8-2.6V | 1-40000mcd | 584-596nm | 15°-180° |
H05AXG4XXXXXXX | YG n | 1.8-2.6V | 1-3000mcd | 564-576nm | 15°-180° |
H05AXG7XXXXXXX | G n | 2.8-3.6V | 200-40000mcd | 515-535nm | 15°-180° |
H05AXB1XXXXXXX | B n | 2.8-3.6V | 200-4000mcd | 450-470nm | 15°-180° |
H05AXWXXXXXXXX | W n | 2.8-3.6V | 200-50000mcd | 2000-100000K | 15°-180° |
